Experience ultra-fast connectivity and superior signal stability with Lanboian’s high-performance 5G MIMO Antennas — engineered for modern wireless communication systems.
Our antennas deliver exceptional data throughput, wide coverage, and low latency, making them ideal for routers, CPEs, IoT devices, and 5G base stations.
Key Features:
Applications:
5G CPE | Industrial Routers | Smart Home Devices | IoT Gateways | Network Infrastructure
| Model | ANT1742D22PG-XP |
| Frequency range | 1710-4200MHz |
| Gain | 27±1dBi；27±1dBi |
| VSWR | <2.0 |
| Polarization | Dual Slant (±45°) |
| Isolation | 25dB |
| Front to Back Ratio | >25dB |
| Horizontal Beam width | 15±5°；12±5° |
| Vertical Beam width | 15±5°；12±5° |
| Maximum Power | 50W |
| Impedance | 50Ω |
| Lighting protection | DC Ground |
| Connector | 2-RPSMA/N Male/N Female |
| Antenna Size | φ0.6m |
| Antenna Weight | 1kg |
| Antenna color | White |
| Diameter of the Pole | Φ30mm to φ50 mm |
| Mechanical Tilt | ±15° |
| Operational Temperature | -40°C to +70°C (-32°F to +158°F) |
